Engine
| Name | L3200D | L3200HD | L3800D | L3800HD | L4600D | L4600HD |
|---|---|---|---|---|---|---|
| Fuel Type | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel |
| Cylinders | 3 | 3 | 3 | 3 | 3 | 4 |
| Engine Model | Kubota D1503 | Kubota D1503 | Kubota D1803 | Kubota D1803 | Kubota V2203 | Kubota V2203 |
| Engine Gross | 30.4 hp | 30.4 hp | 35.9 hp | 35.9 hp | 43.8 hp | 43.8 hp |
| PTO | 26.7 hp | 25.2 hp | 31.5 hp | 30 hp | 38.3 hp | 36.8 hp |
| Displacement | 1,499 cc | 1,499 cc | 1,826 cc | 1,826 cc | 2,197 cc | 2,197 cc |
| Fuel Tank Capacity | 38 l | 38 l | 38 l | 38 l | 48 l | 48 l |
| Rated Speed | 2,800 rpm | 2,800 rpm | 2,700 rpm | 2,700 rpm | 2,700 rpm | 2,700 rpm |
Dimensions
| Name | L3200D | L3200HD | L3800D | L3800HD | L4600D | L4600HD |
|---|---|---|---|---|---|---|
| Length | 2,800 mm | 2,800 mm | 2,800 mm | 2,800 mm | 2,995 mm | 2,995 mm |
| Width | 1,400 mm | 1,400 mm | 1,400 mm | 1,400 mm | 1,585 mm | 1,585 mm |
| Height | 2,330 mm | 2,330 mm | 2,330 mm | 2,330 mm | 2,330 mm | 2,330 mm |
| Wheelbase | 1,610 mm | 1,610 mm | 1,610 mm | 1,610 mm | 1,845 mm | 1,845 mm |
| Ground Clearance | 340 mm | 340 mm | 340 mm | 340 mm | 385 mm | 385 mm |
| Turning Radius | 2.5 m | 2.5 m | 2.5 m | 2.5 m | 2.5 m | 2.5 m |
| Tractor Weight | 1,180 kg | 1,190 kg | 1,205 kg | 1,210 kg | 1,430 kg | 1,450 kg |
This heavy duty tractor range not only performs - but also features modern design touches with smooth, rounded contours from front to rear that also improve visibility so you can get the job done better and faster.
Add to that, Kubota’s state-of-the-art front loader and backhoe options that simplify even tough tasks. Work hard, but do it with ease with the new Standard L Series tractors.
