Engine
| Name | M5091DHC | M5111DHC | M5111DHC-DS | M5091DH | M5111DH |
|---|---|---|---|---|---|
| Fuel Type | Diesel | Diesel | Diesel | Diesel | Diesel |
| Cylinders | 4 | 4 | 4 | 4 | 4 |
| Engine Model | Kubota V3800 | Kubota V3800 | Kubota V3800 | Kubota V3800 | Kubota V3800 |
| Engine Gross | 93 hp | 110.5 hp | 110.5 hp | 93 hp | 110.2 hp |
| PTO | 75 hp | 88 hp | 88 hp | 75 hp | 85.5 hp |
| Displacement | 3,769 cc | 3,769 cc | 3,769 cc | 3,769 cc | 3,769 cc |
| Fuel Tank Capacity | 105 l | 105 l | 105 l | 105 l | 105 l |
| Rated Speed | 2,600 rpm | 2,600 rpm | 2,600 rpm | 2,600 rpm | 2,600 rpm |
Dimensions
| Name | M5091DHC | M5111DHC | M5111DHC-DS | M5091DH | M5111DH |
|---|---|---|---|---|---|
| Length | 3,955 mm | 3,955 mm | 3,750 mm | 3,045 mm | 3,955 mm |
| Width | 2,005 mm | 2,005 mm | 2,005 mm | 1,990 mm | 2,005 mm |
| Height | 2,650 mm | 2,650 mm | 2,650 mm | 2,680 mm | 2,650 mm |
| Wheelbase | 2,250 mm | 2,250 mm | 2,250 mm | 2,250 mm | 2,250 mm |
| Ground Clearance | 520 mm | 520 mm | 520 mm | 520 mm | 520 mm |
| Turning Radius | 3.8 m | 3.8 m | 3.8 m | 3.8 m | 3.8 m |
| Tractor Weight | 3,220 kg | 3,220 kg | 3,220 kg | 2,790 kg | 2,790 kg |
The performance begins with a reliable and efficient Kubota engine that can power through even the toughest tasks with ease and speed. There’s plenty of power for PTO-driven implements, as well as convenient electronic speed control to keep those implements operating at optimum efficiency. A fully synchronised transmission and an advanced hydraulic shuttle for shifting between forward and reverse simplifies tractor operations.
An all-glass cab and a newly designed bonnet ensure excellent visibility in all directions, including both front and rear implements as well as the immediate working environment. The cab glass is curved to reduce glare and enhance spaciousness, while narrow pillars and a sloping bonnet increase visibility in all directions.
