Engine
| Name | B2301HD | B2601HD |
|---|---|---|
| Fuel Type | Diesel | Diesel |
| Cylinders | 3 | 3 |
| Engine Model | Kubota D1005 | Kubota D1005 |
| Engine Gross | 22 hp | 25.5 hp |
| PTO | 17.5 hp | 19.5 hp |
| Displacement | 1,001 cc | 1,123 cc |
| Fuel Tank Capacity | 23 l | 23 l |
| Rated Speed | 2,800 rpm | 2,800 rpm |
Dimensions
| Name | B2302HD | B2601HD |
|---|---|---|
| Length | 2,380 mm | 2,410 mm |
| Width | 1,1150 mm | 1,245 mm |
| Height | 2,130 mm | 2,160 mm |
| Wheelbase | 1,560 mm | 1,560 mm |
| Ground Clearance | 305 mm | 325 mm |
| Turning Radius | 2.1 m | 2.1 m |
| Tractor Weight | 710 kg | 740 kg |
Both models offer a wide range of innovative features to provide more comfort and more efficiency, for the utmost in productivity.
Combine the ease-of-use and versatility with the power and reliability of renowned Kubota engines and transmissions, and you can consider almost any task complete.
