Disc Spreader DS Weighing Series

Disc Spreader DS Weighing Series

Specifications

Specifications

Name DSM-W1300 Geospread DSX-W1875 ISOBUS MkII DSX-W1875 Geospread MkII DSXL-W1875 Geospread Hi-Speed
Basic Hopper Capacity 1,300 L 1,875 L 1,875 L 1,875 L
Max. Hopper Capacity 2,800 L 4,575 L 4,575 L 4,575 L
Max. Permissable Weight in Hopper 2,800 kg 3,900 kg 3,900 kg 3,900 kg
Min. Spreading Width 10 m 12 m 12 m 24 m
Max. Spreading Width 33 m 54 m 54 m 45 m
Max. Flow (Fertiliser Density of 1.55kg/L) 419 kg/min 356 kg/min 356 kg/min 601 kg/min
Hopper Width 2,450 mm 2,900 mm 2,900 mm 2,900 mm
Min. Filling Height 1,130 mm 1,200 mm 1,200 mm 1,200 mm
Max. Filling Height 1,510 mm 1,960 mm 1,960 mm 1,960 mm
Weight – Empty 496 kg 680 kg 680 kg 680 kg
Fully ISOBUS Controlled ✓ ✓ ✓ ✓
4 x Load Cells 2 t 5 t 8 t 5 t
Spinner Drive PTO w/Clutch PTO w/Clutch Hydraulic Hydraulic
Hopper Sieves ✓ ✓ ✓ ✓
Slow Rotating Agitator ✓ ✓ ✓ ✓
Fine Application Kit ✓ ✓ ✓ ✓
LED Road Lighting ✓ ✓ ✓ ✓
Spreading Computer See Options See Options See Options See Options
Hopper Shutter Control Electric Actuators Electric Actuators Electric Actuators Electric Actuators
Spreading Width Adjustment Electric Actuators Manual Lever Electric Actuators Electric Actuators
GEOSPREAD Section Control Section Widths 1 m 4 m 1 m 1 m
GEOSPREAD Section Control Max. Sections Unlimited 16 Unlimited Unlimited

Gallery

Hopper volumes range from 1300 to 1875 L, and optional aluminium hopper extensions increase this to 2800 and 4575 L, respectively, depending on the weight of the fertiliser.

Spreading width varies from 10 m in the DSM-W1300, to an impressive 54 m, all with even distribution and double overlap. Like our DS standard spreaders, Kubota’s weighing spreaders take advantage of our RotaFlow system, which accelerates the fertiliser granules before they reach the spreading vanes for less impact – all easily controlled via the FlowPilot dashboard.
