Specifications
| Name | DSC700 | DSM1100H | DSM1100C | DSX1875H | DSX1875C |
|---|---|---|---|---|---|
| Basic Hopper Capacity | 700 L | 1,100 L | 1,100 L | 1,875 L | 1,875 L |
| Max. Hopper Capacity | 1,400 L | 2,000 L | 2,000 L | 4,575 L | 4,575 L |
| Max. Permissable Weight in Hopper | 1,400 kg | 2,000 kg | 2,000 kg | 3,900 kg | 3,900 kg |
| Min. Spreading Width | 9 m | 10 m | 10 m | 12 m | 12 m |
| Max. Spreading Width | 21 m | 28 m | 28 m | 54 m | 54 m |
| Max. Flow (Fertiliser Density of 1.55kg/L) | 286 kg/min | 419 kg/min | 419 kg/min | 356 kg/min | 356 kg/min |
| Hopper Width | 1,540 mm | 2,200 mm | 2,200 mm | 2,900 mm | 2,900 mm |
| Min. Filling Height | 960 mm | 1,000 mm | 1,000 mm | 1,200 mm | 1,200 mm |
| Max. Filling Height | 1,280 mm | 1,380 mm | 1,380 mm | 1,960 mm | 1,960 mm |
| Weight – Empty | 250 kg | 330 kg | 330 kg | 515 kg | 515 kg |
| Spinner Drive | PTO w/Clutch | PTO w/Clutch | PTO w/Clutch | PTO w/Clutch | PTO w/Clutch |
| Hopper Sieves | ✓ | ✓ | ✓ | ✓ | ✓ |
| Agitator | Yes (Rotates same as disc speed) | Yes (Rotates same as disc speed) | Yes (Rotates same as disc speed) | Yes (Rotates at 15% of disc speed) | Yes (Rotates at 15% of disc speed) |
| Slow Rotating Agitator | ✗ | ✗ | ✗ | ✗ | ✗ |
| Fine Application Kit | ✓ | ✓ | ✓ | ✓ | ✓ |
| LED Road Lighting | ✗ | ✓ | ✓ | ✓ | ✓ |
| Spreading Computer | ✗ | ✗ | Comfort Control II | ✗ | Comfort Control II |
| Hopper Shutter Control (Individual Left/Right Control) | 2 x DA Hydraulic Cylinders | 2 x DA Hydraulic Cylinders | Electric Actuators | 2 x DA Hydraulic Cylinders | Electric Actuators |
| Hopper Ladder | ✗ | Option | Option | Option | Option |
Spreading width varies from 9 m in our compact spreaders, to an impressive 54 m, all with even distribution and double overlap. Gentle agitators rotate the fertiliser before it reaches the spreading vanes, and this smoother acceleration prevents granule fragmentation.
Kubota also does extensive spread testing analysis to map overlap patterns in 3D, which results in precise width, rate and spread charts that make our DS Series spreaders reliable and accurate.
