| Tank, litres | 3000 | 4000 | 5000 | 6000 |
| Pumps, type – l/min | 364-194 / 464-280 | 364-194 / 464-280 | 364-194 / 464-280 | 364-194 / 464-280 |
| Booms, m | EAGLE 18, 20 21, 24, 28, 30 | EAGLE 18 - 30 m | EAGLE 18 - 30 m | EAGLE 18 - 30 m |
| Booms, m | - | - | FORCE 30, 32, 33, 36 | FORCE 30 - 36 |
| Booms, m | TR4 (Aluminium) 24, 28, 30 | TR4 (Aluminium) 24, 28, 30 | TR4 (Aluminium) 24, 28, 30 | TR4 (Aluminium) 24, 28, 30 |
| Booms, m | - | - | B3 MAJOR (Aluminium) 36.5 | B3 MAJOR (Aluminium) 36.5 |
| RinseTank, l | 500 | 500 | 500 | 500 |
| Total height, m | 3.80 | 3.80 | 3.80 | 3.80 |
| Total length, m | 7.21 | 7.21 | 7.60 | 7.60 |
| Length draw to axle, m | 4.61 | 4.61 | 5.46 | 5.46 |
| Turning radius IntelliTrack, m | 6.00 | 6.00 | 8.5 | 8.5 |
| Track width (fixed), m | 1.80 / 2.00 | 1.80 / 2.00 | 3.00 | 3.00 |
| Track width (adj. axle), m | 1.50 - 2.25 | 1.50 - 2.25 | 1.80 - 2.25 | 1.80 - 2.25 |
| Width, m | 3.41 | 3.41 | 3.41 | 3.41 |
| Clearance, m | 0.8 (340/85R48) | 0.8 (340/85R48) | 0.81 (520/85R42 | 0.81 (520/85R42 |
| Weight total (empty tank), kg | 3300 - 3600 | 3400 - 4700 | 4950 - 5850 | 5000 - 5900 |
| Suspension | Optional | Optional | Optional | Optional |
IntelliTrack is a high-end steering drawbar concept that combines an excellent chassis design with advanced electronics. The tracking concept is easy to connect and operate, ensuring safe tracking even in difficult field conditions. IntelliTrack has an integrated safety feature which prevents the cylinders from steering the drawbar when the driving speed is too high for the given track width.
DynamicFluid4 ensures fast, precise control of the spray rate. The system instantly compensates for changes that will affect flow at the nozzles such as rpm changes, acceleration, turning, and AutoSection switching. The system includes a SoftStart feature to prevent pressure peaks, and sensor backup so an electronics fault won’t stop the spray job.
