| Tank, litres | 4100 | 5100 |
| Pumps, type - l/min | 464/10: 280(540) - 464/12: 334 (540) | 464/10: 280 (540) - 464/12: 334 (540) |
| Booms | PARAGON, TWIN FORCE | PARAGON, TWIN FORCE |
| Engine Deitz 6 cyl. 245 hp / 180 kW (Stage IV / Tier 4) | Standard | Standard |
| Hydrostatic 4-wheel transmission (29 or 40 kph) | EcoDrive | EcoDrive |
| Suspension | FloatRide airbag | FloatRide airbag |
| Steering | 4-wheel steering | 4-wheel steering |
| Mechanical track adjustment, cm | 40 cm sliding range | 40 cm sliding range |
| Turning radius 200 cm track width (middle of chassis), cm | 462 | 530 |
| Weight (basis machine, empty)*, kg | 9.470 | 11.600 |
| Weight, front axle, basis machine in transport (empty)*, kg | 5.490 | 6.900 |
| Weight , rear axle, basis machine in transport (empty)*, kg | 3.980 | 4.700 |
| Total length*, m | 9.5 | 10.23 |
| Total height*; cm | 390 | 390 |
| Width with PARAGON boom (24-42.5m), m | 2.55 | 2.55 |
| Width with TWIN FORCE (24 to 30 m), m | 3.00 | 3.00 |
| Width with TWIN FORCE (32 to 36 m), m | 3.34 | 3.34 |
| Track width manual sliding axle** (380/90 R46), cm | 182 - 360 | 182 - 360 |
| Track width HTA axle** (380/90 R46), cm | 180 to 280 | 180 to 280 |
| Wheel base, cm | 370 | 430 |
| Clearance (380/90 R46), cm | 120 / 150 / 165 | 120 / 150 / 165 |
| RinseTank, l | 410 | 600 |
| Fuel tank, l | 320 | 400 |
| Filling capacity water, l/min | 800 | 800 |
| Filling capacity TurboFiller, l/min | 120 | 120 |
* Dimension and weight are given for ALPHA evo 36 m TWIN FORCE boom - 380/90 R46 tyres and chassis clearance 120 cm
** Minimum track width is wider with wider tyres (depending on axle type)
The new large spacious EvoCab II has been specifically developed by HARDI with our '3-pillar design', which sets a new standard of visibility through more than 320° around the sprayer. The cabin is equipped with a pressurisation system plus dust, aerosol and vapor filtering of fresh air, to protect the driver and meet Class 4 requirements. The new climate control system has been tested intensively in a climate chamber to ensure driver comfort in the hottest conditions.
The new ALPHA evo features FloatRide, replacing the earlier standard of coil spring suspension with airbags. This ensures even better boom stability and helps keep ALPHA balanced on steep slopes. Chassis height is maintained regardless of tank volume. By allowing for individual wheel movement of up to 185 mm ALPHA provides maximum comfort, even at high spraying speeds.
